2019 RS 300 R

SWM Motorcycles has the pleasure to announce the new  RS 300 R of Enduro range. “Knobby tyres” fans can rely on the Euro 4 homologated model, it’s reliable engine and a “state of the art” frame let you to go into the off-road sections with easiness and perfect handling.


KAYABA SUSPENSIONS

Adjustable KAYABA 48mm front forks and single hydraulic shock absorber.

FRAME

“State of the art” high strenght steel single beam double cradle main frame

BREMBO BRAKES

Top performance Brembo front and rear brakes.

ENGINE

Powerful and reliable 297,6cc DOHC single cylinder.

Affordability

Maintenance intervals every 1240 miles!

2019

highlights

Dimensions

WHEELBASE: 58.46in

OVERALL LENGTH: 88.18in

OVERALL WIDTH: 32.28in

OVERALL HEIGHT: 50.59in

SADDLE HEIGHT: 37.59in

MIN GROUND CLEARANCE: 11.8in

TRAIL: 4.17in

CURB WEIGHT WITHOUT FUEL: 244.7lbs

FUEL TANK CAPACITY: 1.9gal

MOTOR TYPE: SINGLE CILINDER 4 STROKE

DISPLACEMENT: 297.6cc

COMPRESSION RATIO: 12.9:1

COOLING: LIQUID, 2 WATER RADIATOR AND ELECTRIC FAN

POWER: 37.5HP. DOHC , 4VALVES

LUBRICATION: WET SUMP WITH 2 LOBE OIL PUMPS CARTRIGE FILTER AND RADIATOR OIL

IGNITION: ELECTRONIC , WITH ADJUSTABLE ADVANCE AND DIGITAL CONTROL.

FUEL SYSTEM: ELECTRONIC INJECTION FED

CLUTCH TYPE: WET , MULTIPLATE WITH HYDRAULIC CONTROL

TRANSMISSION: CONSTANT MESH GEAR GEARS, 6 SPEED

FRAME TYPE: HIGH STRENGTH STEEL WITH ROUND PIPES, SINGLE BEAM DOUBLE CRADLE MAIN FRAME, REAR FRAME IN LIGHT ALLOY

FRONT SUSPENSION TYPE: KAYABA UPSIDE DOWN TELESCOPIC HYDRAULIC FORK WITH ADVANCED AXKE, REBOUND DAMPING ADJUSTMENT

REAR SUSPENSION TYPE: PROGRESSIVE “SOFT DAMP” SINGLE HYDRAULIC SHOCK ABSORBER, SPRING PRELOAD, COMPRESSION AND REBOUND ADJUSTEMENTS

FRONT BRAKE TYPE BREMBO, FIXED DISC WITH HYDRAULIC CONTROL AND FLOATING CALIPER. 260MM DISC.

REAR BRAKE TYPE: BREMBO, FIXED DISC WITH HYDRAULIC CONTROL AND FLOATING CALIPER, 240MM DISC.

FRONT RIM: 1.6 x 21”

REAR RIM: 2.15 X 18”

FRONT TIRE: 90 / 90 x 21” – MICHELIN COMPETITION

REAR TIRE: 140 / 80 x 18” – MICHELIN COMPETITION

ELECTRICAL EQUIPMENT: VOLTAGE 12 V /

BATTERY: 12V – 6.3Ah
