2018 ego



The Energica EGO. Designed and built by the same people who have designed and engineered racing performance from Formula One Racing to Le Mans 24h for over 40 years.
Massive Performance, no emissions.
The green heart of the electric motorcycle is a synchronous oil-cooled motor with permanent magnets. It has 107kW (145 hp c.ca) of instantaneous power reaching from 4900 rpm to 10500 rpm and a torque of 144 ft lb ranging from 0 rpm to 4700 rpm.

Energica Ego accelerates from 0 to 60 mph in 3 seconds to reach a top speed of 150 mph with a vigorous thrust that does not make you miss the drops in the engine speed by the constant shifting of the classic internal combustion engines – making the electric superbike faster than a 600 supersport.
The bona fide brain of the Energica Ego is the sophisticated Vehicle Control Unit.
Unlike other vehicles where the control units work separately on all controllers, the Ego’s battery, inverter, charger and ABS are constantly monitored and managed by one technological jewel: the VCU, completely designed and developed by Energica. The state-of-the-art VCU implements a multi-map adaptive energy, and a power management algorithm manages the electric motorcycle. Carefully monitoring and adjusting the motor’s power according to the throttle thrust 100 times per second while riding.


Energica Ego does not have a gearbox or a clutch. Everything is regulated by the ride-by-wire system, allowing you to control the acceleration torque of the motor and deceleration based on the regenerative torque or engine braking. A coasting feature is provided thanks to a “neutral” position between acceleration and regeneration.

The electric motorcycle Energica Ego is also equipped with a “PARK ASSISTANT” in order to facilitate parking and maneuvers on slopes or into rush traffic. The VCU limits both the speed and the torque of the vehicle. The PARK ASSISTANT works back and forth (reverse mode) with maximum speed 1.74 mph and maximum torque 37 ft lb.

Energica Ego braking system is by Brembo and the ABS system is by Bosch. The latest generation ABS BOSCH on Energica Ego not only prevents the wheels from locking but is equipped with rear-wheel lift- up mitigation system that prevents overturn during emergency braking.

The electric motorcycle Energica EGO has a digital dashboard from COBO TFT with an active matrix of 4.3 inches and color display.

The connectivity for the electric motorcycle is supported by Bluetooth (short range) and UMTS long range technology (in progress), allowing you to connect your vehicle to your smartphone, tablet or simply to your home computer via the Internet.

Energica Ego can be recharged through the columns in the outdoor charging stations or at home, equipped with an onboard battery charger with a cable interface on the charging station or remotely via Bluetooth connectivity.

#MyElectricEgo
— Energica Motor Company


Motor:

TYPE

Permanent Magnet AC, Oil Cooled



Performance:

MAX SPEED

Limited at 150 mph

TORQUE

148 ft lb

POWER

107 kW / 145 Hp

RIDING MODES

4 Riding Modes: Urban, Eco, Rain, Sport
4 Regenerative Maps: Low, Medium, High, Off

PARK ASSISTANT

Back and Forth (1.74 mph Max Speed)



Battery:

CAPACITY

11.7 kWh – lithium polymer

LIFE

1200 Cycles @ 80% Capacity (100% DOD)

WARRANTY

3 years on vehicle / 31,000 miles on battery

RECHARGE

30 min (0-85% Soc) Mode 4 Dc Fast Charge
3.5 h (0-100% Soc) Mode 2 or 3 Charge

BATTERY CHARGER

Onboard, [110-220]V [50-60]Hz, 3 kW. Conforms to Standards SAE J1772 and IEC 62196-2 with pilot signal for charging station interface

LPR FUNCTION

Long Period Rest: allows the maintenance and automatic balancing of the batteries during long period of non-use



Components:

FRONT AND REAR WHEEL

Cast Alluminium: front 3.5” x 17” / rear 5.5” x 17”

TYRE

Pirelli Diablo Rosso III – front 120/70 ZR17 / rear 180/55 ZR17

FRAME

Steel Tubular Trellis

SWINGARM

Cast Aluminum

FRONT SUSPENSION

Marzocchi Ø43 mm, Adjustable Rebound and Compression Damping, Spring Preload

REAR MONO

Bitubo Rear Mono Shock Adjustable Rebound, Spring Preload

CHAIN

(16/44) 525 O-Ring Chain

ABS

Bosch Switchable

FRONT BRAKE

Brembo, Double Floating Discs, Ø330 mm, 4 Pistons Radial Caliper

REAR BRAKE

Brembo, Single Disc, Ø240 mm, 2 Pistons Caliper



Electronics:

DASHBOARD

4.3” WQYGA 480×272 TFT Color Display with internal memory for datalogging, integrated GPS receiver and Bluetooth communication 16.7 million colors; 9 Warning Lights; 6 + 6 Current Consumption Lights; Ambient Light Sensor; Real Time Clock; GPS 10Hz. Possibility to view the closest charging stations when connected to MYEnergica App.

CONNECTIVITY

Bluetooth Low Energy

VEHICLE CONTROL UNIT

A Vehicle Control Unit implementing a multi-map adaptive energy and power management algorithm manages the vehicle. It constantly monitors batteries, even in key off position



Dimensions:

SEAT HEIGHT

31.9 inches

WHEELBASE

58.9 inches

LENGTH

84.2 inches

WIDTH

34.3 inches

HEIGHT

45.9 inches (mirrors not included)
